Toshiba Electronic Devices & Storage Corporation ("Toshiba") has launched two products of 600V small intelligent power device (IPD) for brushless DC motor drive applications such as air conditioners, air cleaners, and pumps. Volume shipments of “TPD4163K” and “TPD4164K,” which have output current (DC) ratings of 1A and 2A, respectively, start today.
This press release features multimedia. View the full release here: https://www.businesswire.com/news/home/20231025837780/en/
Toshiba: 600V small intelligent power devices for brushless DC motor drives (Graphic: Business Wire)
Both new products are housed in a through hole type HDIP30 package, which reduces the mounting area by approximately 21% against Toshiba’s previous products[1]. This helps reduce the size of motor drive circuit boards.
As power supply voltage may fluctuate significantly in regions with unstable power supply, the voltage has been increased from the 500V of Toshiba’s previous products[1] to 600V, which improves reliability.
A “Reference Design for Sensorless Brushless DC Motor Drive Circuit” that utilizes the functions of the new TPD4164K with a TMPM374FWUG microcontroller with vector control engine is available from today on Toshiba’s website.
Toshiba will continue to expand its product line-up with improved characteristics, to improve design flexibility, and to contribute to carbon neutrality through energy-saving motor control.
Note:
[1] DIP26 package products (end-of-life products): TPD4123K, TPD4123AK, TPD4144K, TPD4144AK, TPD4135K, TPD4135AK
Applications
Brushless DC motors in home appliances
- Fan motors (air conditioner, air cleaner, ventilation fan, ceiling fan, etc.)
- Pumps
Features
- High power supply voltage rating to secure operation margin for power supply voltage fluctuations: VBB=600V
- Small package
Through hole type HDIP30: 32.8mm×13.5mm (typ.), t=3.525mm (typ.)
| Main Specifications | ||||||
| (Ta=25°C unless otherwise specified) | ||||||
| Part number | ||||||
| Absolute maximum ratings | Power supply VBB (V) | 600 | ||||
| Output current (DC) Iout (A) | 1 | 2 | ||||
| Operation ranges | Operating power supply voltage VBB (V) | max | 450 | |||
| Electrical Characteristics | Output saturation voltage | VCEsatH (V) | typ. | 2.6 | 3.0 | |
| VCEsatL (V) | ||||||
| FRD forward voltage | VFH (V) | typ. | 2.0 | 2.5 | ||
| VFL (V) | ||||||
| Package | Type | Through hole | ||||
| Toshiba’s name | HDIP30 | |||||
| Size (mm) | 32.8×13.5 (typ.), t=3.525 (typ.) | |||||
| Protect function | Over-current/thermal shutdown/under-voltage/ | |||||
| Sample Check & Availability | ||||||
Follow the links below for more on the new products.
TPD4163K
TPD4164K
Follow the link below for more on Toshiba Intelligent Power ICs.
Intelligent Power ICs
Follow the links below for more on Toshiba’s solutions proposals using the new products.
Application
Air Conditioners
Air Cleaners
To check availability of the new products at online distributors, visit:
TPD4163K
Buy Online
TPD4164K
Buy Online
